Transborder for furnace charges for aluminum processing

This process transfer table, with a capacity of 90 tons and powered by a busbar system, is designed for handling the production of aluminum sheets. It operates on a specially prepared track made of railway rails and is intended for transporting furnace charges within a building. The table is an example of a specialized technical solution, designed and built for specific conditions.

Application:

The transfer table is intended for loading furnace charges for aluminum processing.

Call us

Find a branch

Print

Parameters	*Photo	Range
Load capacity	90 000 kg	as required
Length	31 700 mm	as required
Travel speed	max. 6 m/min	as required
Power supply	conductor rail	as required
Control method	radio or local panel	as required
Track	rawilway tracks	as required
Purpose	transporting furnace charges	-
Catalog number	PL060465

Transborder for furnace charges for aluminum processing

This process transborder, with a capacity of 90 tons and powered by a busbar system, is designed for handling the production of aluminum sheets. It operates on a specially prepared track made of railway rails and is intended for transporting furnace charges within a building. The table is an example of a specialized technical solution, designed and built for specific conditions.

Application:

the transborder is intended for loading furnace charges for aluminum processing.

Description:

the parameters provided can be customized to meet the specific needs of the user.
